1 - 2 of 2
Description
Price
Quantity
Doug Fleenor Design DMXDecelerator-5
DMX512 Isolator and Re-Timing Device
Ship Weight 3 lbs.
Item#:
DMXDECELERATOR-5
Available:
Special Order/Direct Ship
Call to order
Doug Fleener Design Node4
Ethernet to DMX Interface / Artnet - sACN
Ship Weight 9 lbs.
PORT SPECIFICATIONS
PORT SPECIFICATIONS
- Port circuit: EIA-485 transceiver with 120 ohm fail safe termination between +Data and -Data
- NOTE: This product uses a slew-rate-limited output drivers. Slew- rate-limited drivers minimize EMI and reduce reflections caused by improperly terminated cables.
- Input signal: 0.2 volts minimum, 12 volts maximum
- Output signal: 1.5 volts (minimum) into 120 Ohm Termination
- Connectors: Gold plated 5 pin XLR (typically four female connectors, male on request), Terminal Blocks Optional
- Port protection: +60V continuous, +15KV transient
- Isolation: 600 volts
- Ethernet Circuit: 100BASE-TX Fast Ethernet, Auto detects if crossover or regular cable is used, and speed negotiation up to 100Mbits.
- Connector: Neutrik Ethercon
- Isolation: 1500 Volts
- Network Protocols: Artnet, Streaming ACN, Draft Streaming ACN
- MAIN SPECIFICATIONS
- Power input: 6W, 100 to 240 VAC 50/60 Hz
- Color: Front, Back: Black
- Top, Bottom, Sides: Silver Hammertone
- Size and weight: 10.375" deep, 1.7" high, 16.5" wide 6 pounds
Call to order
1 - 2 of 2
