Elation Platinum Seven
Patent Pending High Power 7 Color Wash Luminaire
(19) 25W Multi-Chip LEDs (RGBW+Amber+Cyan+UV)
5° - 50° Beam Angle Zoom Range
Advanced Cooling and Movement Control Systems
Silent Mode - Reduces Fan Noise by 25% Decibels
(3) Pixel Ring Control and Color-Pixel Ring Macro Effects
CRI Presets (85, 90, 95)
Linear Color Temperature Presets (2,700 - 8,000K)
Linear Dimming and Selectable Dimming Curves
Flicker Free Operation for TV and FILM
Adjustable Refresh Rate Frequency and GAMMA
DMX, RDM, KlingNET⢠and Art-NET (DMX Over Ethernet)
SOURCE
(19) 25W Multi-Chip LEDs
50,000 Hour Average LED Life**
**LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
38,500 LUX 3,577 FC @3.3' (1m) (5° Min Zoom) Full ON
6,670 LUX 620 FC @3.3' (1m) (50° Max Zoom) Full ON
EFFECTS
5° - 50° Beam Angle Zoom
(3) Zone Ring Control
Color-Pixel Ring and Color Preset Macros
CRI Presets (85, 90, 95)
Linear Color Temperature Presets (2,700 - 8,000K)
Electronic Strobe (1-25 fps)
Linear Dimming 0-100% + Selectable Dimming Curves
COLOR
RGBW + AMBER + CYAN + UV (7 Colors)
Even and Smooth Color Mixing
CONTROL / CONNECTIONS
(3) DMX Channel Modes (24 / 31 / 40)
Adjustable Refresh Rate
(900-1500, 2500, 4000, 5000, 10000, 15000 ,20000, 25000 (Hz)
Adjustable Gamma Brightness (2.0, 2.2, 2.4, 2.8)
Silent Mode
RDM (Remote Device Management)
6 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
8 / 16 Bit Resolution Adjustable Movement
5pin DMX In/Out
RJ45 Ethernet In/Out (Art-NET)
powerCON TRUE1 Power In/Out
SIZE / WEIGHT
Length: 16.5" (418.1mm)
Width: 11.2" (284.4mm)
Vertical Height: 22" (558.9mm)
Weight: 47.0 lbs. (21.3 kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
Max Power Consumption: 600W
14°F to 113°F (-10°C to 45°C)
APPROVALS / RATINGS
CE | RoHs | IP20
Elation Fuze Wash Z120
120W RGBW COB LED Moving Head Wash Luminaire
RGBW Color Mixing
7° TO 55° Wide Motorized Zoom Range
Variable Dimming Curves
Multiple Unit Power Linking
RDM (Remote Device Management)
Flicker Free Operation for TV and FILM
SOURCE
120W RGBW COB LED
100,000 Hour Average Lamp Life*
*LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
10,640 LUX 988 FC @9.8' (3m) (7° Full ON)
692 LUX 64 FC @9.8' (3m) (55° Full ON)
COLOR
RGBW
EFFECTS
RGBW Color Mixing
7° - 55° Beam Zoom Range
Electronic Strobe, Dimming and Variable Dimming Curves
64 Color Presets and 14 Unique Color Macros
CONTROL / CONNECTIONS
4 DMX Channel Modes (19 Total Channels)
7 Button Control Panel and LCD Menu Display
RDM (Remote Device Management)
3pin/5pin DMX and powerCON In/Out
SIZE / WEIGHT
Length: 13.3" (338mm)
Width: 9.0" (229mm)
Vertical Height: 18.2" (466mm)
Weight: 22 lbs. (10 kg)
ELECTRICAL / THERMAL
AC 110-240V - 50/60Hz
157W Max Power Consumption
Multiple Unit Power Linking
5°F to 113°F (-15°C to 45°C)
APPROVALS / RATINGS
CE | RoHs | IP30
Elation Fuze Wash Z350
350W RGBW COB LED Moving Head Wash Luminaire
RGBW Color Mixing
10° to 46° Wide Motorized Zoom Range
Variable Dimming Curves
Multiple Unit Power Linking
RDM (Remote Device Management)
Flicker Free Operation for TV and FILM
SOURCE
350W RGBW COB LED
100,000 Hour Average Lamp Life*
*LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
COLOR
RGBW
EFFECTS
RGBW Color Mixing
6° to 46° Beam Zoom Range
Electronic Strobe, Dimming and Variable Dimming Curves
64 Color Presets and 14 Unique Color Macros
CONTROL / CONNECTIONS
4 DMX Channel Modes (19 Total Channels)
7 Button Control Panel and LCD Menu Display
RDM (Remote Device Management)
3pin/5pin DMX and powerCON In/Out
SIZE / WEIGHT
Length: 16.3" (414mm)
Width: 11.6" (294mm)
Vertical Height: 18.0" (461mm)
Weight: 45 lbs. (20.4 kg)
ELECTRICAL / THERMAL
AC 110-240V - 50/60Hz
380W Max Power Consumption
Multiple Unit Power Linking
5°F to 113°F (-15°C to 45°C)
APPROVALS / RATINGS
CE | RoHs | IP30
Elation Fuze Wash 575
Features
- Cool White / Daylight Single Source Par Moving Head
- High Output 95CRI 6,800K COB LED
- 11° to 40° Motorized Zoom
- Smooth 16-Bit Pan and Tilt Movement
- Variable Dimming Curve Modes
- RDM (Remote Device Management)
- Flicker Free Operation for TV and FILM
Multiple Unit Power Linking
Optional Snoot Lens
Specifications
SOURCE
350W 95CRI 6,800K Cool White / Daylight COB LED
50,000 Hour Average LED Life*
*May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
35,425 LUX 3,291 FC @6.6' (2m) (11° Full On)
6,502 LUX 604 FC @6.6' (2m) (40° Full On)
EFFECTS
11° - 40° Motorized Zoom
Electronic Strobe
Variable Dimming Curve Modes
COLOR
Cool White / Daylight
CONTROL / CONNECTIONS
2 DMX Channel Modes (11 Total Channels)
7 Button Control Panel and LCD Menu Display
Smooth 16-Bit Pan and Tilt Movement
RDM (Remote Device Management)
5pin DMX and powerCON TRUE1 In/Out
SIZE / WEIGHT
Length: 13.3” (337.7mm)
Width: 9.0” (228.8mm)
Vertical Height: 18.33” (465.7mm)
Weight: 27.0 lbs. (12.2kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
425W Max Power Consumption
Multiple Unit Power Linking
5°F to 113°F (-15°C to 45°C)
INCLUDED ITEMS
Omega Brackets
powerCON TRUE1 Power Cable
APPROVALS / RATINGS
CE | IP30
