ADJ SAB605

Saber Spot LED Pin Spot Warm White
Specifications
Optical
• Light Source: 15-Watt Warm White LED
• LED Life Expectancy: 10,000 Hrs
• Beam Angle: 4-degrees
• Includes 2 interchangeable frost filter lens (10-degree & 45-degree)
• Refresh Rate: 3.6KHz

Technical Features
• 4-button Digital Display for easy navigation
• Electronic Dimming 0 – 100%
• Flicker Free
• Includes a scissor yoke to be hung or set on the ground

Connections
• Power Input: powerCON
• Power Pass through: powerCON
• Control: 3 Pin DMX In/Out pigtails
• With Wired Digital Communication Network

Control
• 2 DMX Channel Modes: 1 or 2

Electrical
• Input Voltage: 100-240V 50Hz/60Hz (Auto Sensing)
• Power draw 120V 60Hz: 15W, 0.13 Amps
• Power draw 220V 50Hz: 15W, 0.07 Amps

Physical
• Dimensions (LxWxH): 3.5” x 6.75” x 3.5” / 88 x 170 x 87mm
• Weight: 2.6 lbs / 1.2 kg.
• Metal Black Housing

Certifications
• ETL Approved, UL, CE
• IP 20: Dry area, No liquids

What’s Included
• Manual
• powerCON power cord
• 2 frost filter lens (10-degree & 45-degree)
• O-ring for frost filter lens

Optional Accessories
• PLC 3,PLC 6, PLC 10 (powerCON passthrough cables)
Item#:
SAB605
Available:
Special Order/Direct Ship
164.99
Each

ADJ SAB990

Saber Spot LED Pin Spot Dim To Warm
Specifications
Optical:

  • Light Source: 15-Watt Warm White LED
  • LED Life Expectancy: 10,000 Hrs
  • Beam Angle: 20-degrees
  • Includes 2 interchangeable frost filter lens (10-degree & 45-degree)
  • Color Temperature (Full on): 3100K (Warm White); 1900K (Amber)
  • LUX: 726 @ 3M
  • CRI (Full on): 92
Control:
  • 3 DMX Channel Modes: 1, 2 or 4
  • 4-button Digital Display for easy navigation
  • Electronic Dimming 0 – 100%
  • 5 Dimming Curve modes
  • Dim to warm effect with Amber LED
  • Flicker Free (Refresh Rate: 3.6KHz)
  • Variable Strobe: 1-20Hz
Connections:
  • Power Input: powerCON
  • Power Pass through: powerCON
  • Daisy chain quantity: 33 fixtures (@120V); 71 fixtures (@230V)
  • Control: 3-pin DMX In/Out pigtails
  • With Wired Digital Communication Network
Electrical:
  • Input Voltage: 100-240V 50Hz/60Hz (Auto Sensing)
  • Power draw 120V 60Hz: 15W, 0.13 Amps
  • Power draw 220V 50Hz: 15W, 0.07 Amps
  • Power Consumption: 24W
Physical:
  • Dimensions (L x W x H): 3.5” x 6.75” x 3.5” / 88 x 170 x 87mm
  • Weight: 2.6 lbs / 1.2 kg.
  • Metal Black Housing
Certifications:
  • ETL Pending, UL, CE
  • IP 20: Dry area, No liquids


Item#:
SAB990
Available:
Special Order/Direct Ship
164.99
Each
