Chauvet Maverick MK1 Spot

350W White LED-CMY Spot Fixture

At a Glance

  • Fully featured 350W LED yoke spot fixture including CMY color mixing, a color wheel, zoom optics, and two gobo wheels, one rotating, and one static

  • 16-bit dimming of master dimmer for smooth control of fades

  • Variable CMY color mixing system to create a wide pallet of colors

  • DMX, WDMX, sACN, and Art-Net for full flexibility of control options

  • RDM Enabled for remote addressing and trouble shooting

  • Converts TCP/IP to DMX for shorter data cable runs

  • 7° to 33° zoom angle for variable beam sizes

  • Iris, 3-facet prism, and frost for beam control

  • True 1 compatible power input

  • Battery backup touchscreen display with auto rotate depending on fixture orientation

Specifications

Optical

  • Light Source: 1 LED (CW) 350 W, (9.6 A), 6,808 K, 50,000 hours life expectancy
  • Beam Angle: 7° to 29°
  • Field Angle: 7° to 33°
  • Zoom Angle: 7° to 33°
  • Illuminance (7°): 34,282 lux @ 5 m
  • Illuminance (33°): 2,097 lux @ 5 m
  • Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

Dynamic Effects

  • Pan and Tilt: 540°/270°
  • Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
  • Colors: 7 + white, split colors, continuous scroll at variable speeds
  • Colors: CMY flags
  • Gobos (1): 7 + open (7 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
  • Gobos (2): 7 + open (7 metal), continuous scroll at variable speeds
  • Gobo Size (1): Gobo Wheel 1 (rotating): 26 mm (outside), 22 mm (image), 1.2 mm (max. thickness)
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Motorized
  • Focus: Motorized
  • Frost: Motorized
  • Iris: Motorized
  • Prism: 3 Facets, motorized, rotating
  • Strobe Rate: 0 to 20 Hz
  • Move-in-Black: Yes
  • Dim Curves: 4

Construction / Physical

  • Dimensions: 15.5 x 9.8 x 25.0 in (394 x 250 x 636 mm)
  • Weight: 60 lb (27.2 kg)
  • Exterior Color: Black
  • Housing Material: High-impact flame-retardant polymer

Connections

  • Power Connection: Edison plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Data Connectors: 3- and 5-pin XLR
  • Cable Length (power): 5 ft (1.5 m)

Control

  • Control Protocol: Art-Net, sACN, DMX, W-DMX
  • DMX Channels: 22 or 29
  • Art-Net Channels: 22 or 29
  • Modes/Personalities: 2 personalities (22, 29)

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 592 W, 5.07 A @ 120 V, 60 Hz
  • Power and Current: 555 W, 2.74 A @ 208 V, 60 Hz
  • Power and Current: 536 W, 2.47 A @ 230 V, 50 Hz

Certifications / Qualifications

  • CE, MET
  • IP Rating: IP20, dry location

What's Included

  • Seetronic Powerkon IP65 power cord
  • Omega bracket with mounting hardware
Item#:
MAVERICKMK1SPOT
Available:
Special Order/Direct Ship
You must be logged in to order this item. Log in here

Chauvet Maverick MK2 Spot

440W White LED/ CMY Moving Yoke Spot

Optical

  • Light Source: 1 LED (CW) 440 W, (5.6 A), 6808 K, 50,000 hours life expectancy
  • Color Temperature (at full): 6808 K
  • CRI: 73
  • Beam Angle: 12° to 35°
  • Field Angle: 13° to 37°
  • Zoom Angle: 13° to 37°
  • Illuminance (13°): 18,079 lux @ 5 m
  • Illuminance (37°): 2,518 lux @ 5 m
  • PWM Frequency: 1,100 Hz

Dynamic Effects

  • Pan and Tilt: 540°/270°
  • Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
  • Colors: 7 + white, split colors, continuous scroll at variable speeds
  • Colors: CMY flags, CTO flag
  • Gobos (1): 6 + open (6 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
  • Gobos (2): 6 + open (6 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
  • Gobo Size (1) : Gobo Wheel 1 (rotating): 32 mm (outside), 28 mm (image), 3.3 mm (max. thickness)
  • Gobo Size (2) : Gobo Wheel 2 (rotating): 32 mm (outside), 28 mm (image), 3.3 mm (max. thickness)
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Motorized
  • Focus: Motorized
  • Frost: Motorized
  • Iris: Motorized
  • Prism: 3 Facets, motorized, rotating
  • Strobe Rate: 0 to 20 Hz
  • Move-in-Black: Yes
  • Dim Curves: 4

Construction / Physical

  • Dimensions: 15.1 x 9.8 x 26.4 in (385 x 250 x 671 mm)
  • Weight: 62.8 lb (28.5 kg)
  • Exterior Color: Black
  • Housing Material: High-impact flame-retardant polymer

Connections

  • Power Connection: Edison plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Data Connectors: 3- and 5-pin XLR, Neutrik
  • Cable Length (power): 5 ft (1.5 m)

Control

  • Control Protocol: Art-Net, sACN, DMX, W-DMX
  • DMX Channels: 24 or 32
  • Art-Net Channels: 24 or 32
  • Modes/Personalities: 2 personalities (24, 32)

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 740 W, 6.01 A @ 120 V, 60 Hz
  • Power and Current: 723 W, 3.63 A @ 208 V, 60 Hz
  • Power and Current: 700 W, 3.33 A @ 230 V, 50 Hz

Certifications / Qualifications

  • CE, MET
  • IP Rating: IP20, dry location

What's Included

  • Maverick MK2 Spot
  • Seetronic Powerkon IP65 power cord
  • Omega bracket with mounting hardware
Item#:
MAVERICKMK2SPOT
Available:
Special Order/Direct Ship
You must be logged in to order this item. Log in here

Chauvet Rogue RX1 Spot

170W White LED-Color Wheel Spot Fixture

At a Glance

  • Bold, bright 170 W LED light engine for punchy, solid beams

  • Color wheel with 8 colors, split color ability, and continuous variable-speed scrolling

  • Two gobo wheels: one fixed slot scrolling wheel and one rotating, interchangeable, scrolling wheel

  • Iris and 3-facet prism for stunning visual effects

  • Neutrik® powerCON® power input/output connections for power linking

  • 3- and 5-pin DMX input/output connections

  • RDM enabled for remote addressing and trouble shooting

  • Selectable LED maximum output to match legacy Rogue R1 Spots

  • Selectable PWM settings to maintain flicker free operation on camera

  • Simple and complex DMX channel profiles for programming versatility


    Specifications

    Optical

    • Light Source: 1 LEDs (CW) 170 W, (7.4 A), 9491 K, 50,000 hours life expectancy
    • Color Temperature (at full): 9491 K
    • Beam Angle: 16°
    • Illuminance (total): 4,620 lux @ 5 m
    • Selectable LED Power output: 50-100
    • Selectable PWM: 600 Hz, 1,200 Hz, 6,000 Hz, 15,000 Hz

    Dynamic Effects

    • Pan and Tilt: 540°/250°
    • Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 250° tilt
    • Colors: 8 + white, split colors, continuous scroll at variable speeds
    • Gobos (1): 7 + open (7 metal), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
    • Gobos (2): 8 + open (8 metal),continuous scroll at variable speeds
    • Gobo Size: Gobo Wheel 1 (rotating): Positions 1, 2, 3, 4, and 7 (metal); size: 26.9 mm (outside), 22.5 mm (image), 0.5 mm (max. thickness)
    • Gobo Size: Gobo Wheel 1 (rotating): Positions 5 and 6 (glass); size: 25 mm (outside), 23 mm (image), 3 mm (max thickness)
    • Dimmer: Electronic
    • Shutter/Strobe: Electronic
    • Focus: Motorized
    • Iris: Motorized
    • Prism: 3 Facets, motorized, rotating
    • Strobe Rate: 0 to 22 Hz
    • Move in Black: Yes

    Construction / Physical

    • Dimensions (single unit): 11.10 x 14.20 x 17.60 in (282 x 360 x 447 mm)
    • Weight (single unit): 37.6 lb (17.1 kg)
    • Exterior Color: Black
    • Housing Material: High-impact flame-retardant polymer

    Connections

    • Power Connection: Edison (Local) plug to Neutrik® powerCON®
    • Power Input: Neutrik® powerCON®
    • Power Output: Neutrik® powerCON®
    • Data Connectors: 3- and 5-pin XLR
    • Cable Length (power): 5 ft (1.5 m)

    Control

    • Control Protocol: DMX, RDM
    • DMX Channels: 16 or 19
    • Modes/Personalities: 2 personalities (16, 19)

    Electrical

    • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
    • Power Linking: 5 units @ 120 V; 9 units @ 208 V; 10 units @ 230 V
    • Power and Current: 319 W, 2.69 A @ 120 V, 60 Hz
    • Power and Current: 303 W, 1.49 A @ 208 V, 60 Hz
    • Power and Current: 297 W, 1.33 A @ 230 V, 50 Hz

    Certifications / Qualifications

    • CE, MET
    • IP Rating: IP20, dry location

    What's Included

    • Rogue R1X Spot
    • Neutrik powerCON power cord
    • 2 Omega brackets with mounting hardware
Item#:
ROGUER1XSPOT
Available:
Special Order/Direct Ship
You must be logged in to order this item. Log in here

Chauvet Rogue RX2 Spot

300W White LED-Split Color Wheel Spot Fixture

At a Glance

  • Intense 300 W LED light engine for punchy, bold beams

  • Perfect gobo morphing between gobo wheels

  • Two color wheels with 7 colors, split color ability, and continuous variable speed scrolling

  • Two gobo wheels: one fixed slot scrolling wheel and one rotating, interchangeable, scrolling wheel

  • Iris, 3-facet prism, and frost for beam control

  • Beautiful 16-bit LED dimming for ultimate fade control

  • Neutrik® powerCON® power input/output connections for power linking

  • 3- and 5-pin DMX input/output connections

  • RDM enabled for remote addressing and trouble shooting

  • Selectable LED maximum output to match legacy Rogue R2 Spots

  • Selectable PWM settings to maintain flicker-free operation on camera

  • Simple and complex DMX channel profiles for programming versatility


    Specifications

    Optical

    • Light Source: 1 LEDs (CW) 300 W, (8.7 amps), 7,836 K, 50,000 hours life expectancy
    • CRI: 72
    • Beam Angle: 16.5°
    • Field Angle: 16.5°
    • Lumens – Source: 23,000
    • Lumens – Output: 11,000
    • Illuminance (total): 9,187 lux @ 5 m
    • Selectable PWM: 600 Hz, 1,200 Hz, 6,000 Hz, 15,000 Hz

    Dynamic Effects

    • Pan and Tilt: 540°/250°
    • Pan and Tilt Ranges: 540°, 360°, 180° pan/250°, 180°, 90° tilt
    • Colors (1): 7 + white, split colors, continuous scroll at variable speeds
    • Colors (2): 7 + white, split colors, continuous scroll at variable speeds
    • Gobos (1): 7 + open (7 metal), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
    • Gobos (2): 8 + open (8 metal), continuous scroll at variable speeds
    • Gobo Size: Gobo Wheel 1 (rotating): Positions 1, 2, 3, 4, and 7 (metal); size: 28.8 mm (outside), 23.8 mm (image), 0.5 mm (max. thickness)
    • Gobo Size: Gobo Wheel 1 (rotating): Positions 5 and 6 (glass); size: 27 mm (outside), 24 mm (image), 3 mm (max. thickness)
    • Framing Shutters: No
    • Dimmer: Electronic
    • Shutter/Strobe: Electronic
    • Focus: Motorized
    • Frost: Motorized
    • Iris: Motorized
    • Prism: 3 Facets, motorized, rotating
    • Strobe Rate: 0 to 22 Hz
    • Standalone Color Mixing: No
    • Color Temperature Presets: No
    • Move-in-Black: Yes

    Construction / Physical

    • Dimensions (single unit): 16.1 x 13.5 x 19.25 in (409 x 343 x 489 mm)
    • Weight (single unit): 47.8 lb (21.7 kg)
    • Exterior Color: Black
    • Housing Material: High-impact flame-retardant polymer

    Connections

    • Power Connection: Edison (local) plug to Neutrik® powerCON®
    • Power Input: Neutrik® powerCON®
    • Power Output: Neutrik® powerCON®
    • Data Connectors: 3- and 5-pin XLR
    • Cable Length (power): 5 ft (1.5 m)

    Control

    • Control Protocol: DMX, RDM
    • DMX Channels: 18 or 21
    • Modes/Personalities: 2 personalities (18, 21)

    Electrical

    • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
    • Power Linking: 3 units @ 120 V; 6 units @ 208 V; 7 units @ 230 V
    • Power and Current: 517 W, 4.31 A @ 120 V, 60 Hz
    • Power and Current: 427 W, 2.05 A @ 208 V, 60 Hz
    • Power and Current: 437 W, 1.9 A @ 230 V, 50 Hz
    • Breaker Size: F 7A, 250 V

    Certifications / Qualifications

    • CE, MET
    • IP Rating: IP20, dry location
    • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

    What's Included

    • Rogue R2X Spot
    • Neutrik powerCON power cord
    • Omega bracket with mounting hardware
Item#:
ROGUER2XSPOT
Available:
Special Order/Direct Ship
You must be logged in to order this item. Log in here
