Elation ACL 360 Matrix

RGBW LED Multi Beam Moving head Fixture

Features

  • Versatile 14° Moving Head Effect Luminaire
  • New Advanced Collimator Lens
  • (25) Pixel Control RGBW 4-in1 LEDs
  • Laser-Like Homogenized 4° Color Changing Beams
  • Fast and Precise 16-Bit Continuous 360° Pan/Tilt Rotation
  • Strobe and Selectable Dimming Curve Effects
  • DMX, RDM, KlingNET™ and Art-NET (DMX Over Ethernet) Support
  • Flicker Free Operation for Broadcast TV and FILM

Specifications

SOURCE
(25) 15W RGBW 4-in-1 LEDs
100,000 Hour Average LED Life*
*LED Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

PHOTOMETRIC DATA (14° Full ON)
77,344 LUX 7,185 FC @3.3’ (1m)
70,370 LUX 6,537 FC @6.6’ (2m)
54,413 LUX 5,055 FC @9.8’ (3m)
40,505 LUX 3,763 FC @13.1’ (4m)
29,722 LUX 2,761 FC @16.4’ (5m)

EFFECTS
Individual Pixel Control
Strobe and Selectable Dimming Curves

COLOR
RGBW

CONTROL / CONNECTIONS
(3) DMX Channel Modes (17 / 19 / 115)
RDM (Remote Device Management)
6 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
8 / 16 Bit Resolution Adjustable Movement
3pin/5pin DMX In/Out
RJ45 Ethernet In/Out (Art-NET)
powerCON Power In/Out

SIZE / WEIGHT
Length: 19.0” (481mm)
Width: 13.8” (350mm)
Vertical Height: 23.0” (583mm)
Weight: 42.0 lbs. (19 kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
425W Max Power Consumption
5F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS
CE | cETLus | IP30

INCLUDED ITEMS
Omega Brackets
powerCON Cable
Item#:
ACL001
Available:
Special Order/Direct Ship
You must be logged in to order this item. Log in here

Elation ACL013

RGBW LED ACL 360 Bar

Features

  • Versatile 31° Beam Moving Bar Effect Luminaire
  • New Advanced Collimator Lens
  • (7) Pixel Control RGBW 4-in1 LEDs
  • Laser-Like Homogenized 4° Color Changing Beams
  • Fast and Precise 16-Bit Continuous 360° Pan/Tilt Rotation
  • Strobe and Selectable Dimming Curve Effects
  • DMX, RDM, KlingNET™ and Art-NET (DMX Over Ethernet) Support
  • Flicker Free Operation for Broadcast TV and FILM

Specifications

SOURCE
(7) 15W RGBW 4-in-1 LEDs
100,000 Hour Average Lamp Life*
*LED Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.


PHOTOMETRIC DATA (31° Full ON)
44,440 LUX 4,128 FC @3.3’ (1m)
25,260 LUX 2,347 FC @6.6’ (2m)
15,430 LUX 1,433 FC @9.8’ (3m)
10,960 LUX 1,018 FC @13.1’ (4m)
8,081 LUX 751 FC @16.4’ (5m)

EFFECTS
Individual Pixel Control
Strobe and Selectable Dimming Curves

COLOR
RGBW

CONTROL / CONNECTIONS
(3) DMX Channel Modes (17 / 19 / 43)
RDM (Remote Device Management)
6 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
8 / 16 Bit Resolution Adjustable Movement
3pin/5pin DMX In/Out
RJ45 Ethernet In/Out (KlingNET™ / Art-NET)
powerCON Power In/Out

SIZE / WEIGHT
Length: 22.6” (575mm)
Width: 7.2” (184mm)
Vertical Height: 10.2” (258mm)
Weight: 22.0 lbs. (10 kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
135W Max Power Consumption
5F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS
CE | cETLus | IP30

INCLUDED ITEMS
Omega Bracket
powerCON Cable
Item#:
ACL013
Available:
Special Order/Direct Ship
You must be logged in to order this item. Log in here

Elation ACL 360i

RGBW 60W LED-Single Beam Moving Head Fixture
SOURCE
60W RGBW 4-in-1 LED
100,000 Hour Average LED Life*

*LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.


PHOTOMETRIC DATA
30,601 LUX 2,843 FC @6.6' (2m)
12,955 LUX 1,204 FC @9.8' (3m)
7,687 LUX 714 FC @13.1' (4m)
5,112 LUX 475 FC @16.4' (5m)

EFFECTS
Strobe and Selectable Dimming Curves
Color Macros

COLOR
RGBW

CONTROL / CONNECTIONS
(3) DMX Channel Modes (16 / 18 / 20)
RDM (Remote Device Management)
6 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
8 / 16 Bit Resolution Adjustable Movement
5pin DMX In/Out
RJ45 Ethernet In/Out (KlingNET / Art-NET)
powerCON Power In/Out

SIZE / WEIGHT
Length: 8.7" (222mm)
Width: 7.3" (186mm)
Vertical Height: 13.0" (330mm)
Weight: 11.5 lbs. (5.2 kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
110W Max Power Consumption
5F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS
CE | IP30

INSTALLATION
Rigging: Clamps (Not Included)

INCLUDED ITEMS
10° Frost Lens
45° Frost Lens
Omega Bracket
powerCON Cable
Item#:
ACL078
Available:
Special Order/Direct Ship
You must be logged in to order this item. Log in here

Elation Platinum Beam 5R Extreme

189W Discharge Lamp-Single Beam Moving Head Fixture
FEATURES
3° Sharp Pin Spot Beam
CTO and CTB Color Correction
8 Facet Rotating Prism and Frost Effects
Super Fast 16 bit 3-Phase Pan and Tilt Motors
Flicker Free Operation for TV and FILM
Internal EWDMX Wireless DMX Receiver
Remote Device Management Protocol Support

SOURCE
Philips 189W Platinum 5R Lamp
3,000 Hour Average Life*

*Applies to Philips™ 5R lamps with a production date of February 25, 2015, or later. Actual lamp life may vary depending on several factors including but not limited to: environmental conditions, power/voltage, usage patterns (on-off cycling), control, and dimming.


PHOTOMETRIC DATA
100,100 LUX 9,299 FC @49.2' (15M)

EFFECTS
Frost
Motorized Focus
Strobe (1-18 fps)
Electronic Dimming: 0% - 100%
8 Facet Rotating Prisms and Macros

COLOR
(11) Colors Including UV, CTO, and CTB

GOBOS
(8) Metal Rotating, Indexing, Interchangeable Gobos

CONTROL / CONNECTIONS
(3) DMX Channel Modes (12 / 14 / 18)
Remote Device Management
Pan Movement: 540°/630° / Tilt Movement: 270°
6 Button Control Panel
Full Color 180° Reversible LCD Menu Display
16 Bit 3-Phase Pan/Tilt Motors
3pin & 5pin DMX In/Out
powerCON In
Internal EWDMX Wireless DMX Receiver

SIZE / WEIGHT
Length: 13.9" (352mm)
Width: 13.0" (329mm)
Vertical Height: 20.0" (509mm)
Weight: 44.0 lbs. (20.0 kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
350W Max Power Consumption
14°F to 113°F (-10°C to 45°C)

APPROVALS / RATINGS
CE | cETLus | IP20

INSTALLATION
Rigging: Omega Bracket
Working Position: Flat Surface / Inverted (180°)
You must be logged in to order this item. Log in here

Elation Proteus Beam

Platinum 14R Discharge Lamp Beam Fixture/ IP65 Rated

Features

IP65 Rated Moving Head Beam Luminaire
Philips™ MSD Platinum 14R 280W 80CRI 7,800K Lamp
Precise 2.5° Beam Aperture and Advanced Optics
Revolutionary Internal Cooling System
Full CMY Color Mixing
13 Dichroic Colors including CTB, CTO, and UV
8 Rotating Interchangeable and 13 Static-Stamped Metal Gobos
5 and 32 Facet Rotating Prisms and Frost Filter
Motorized Focus and Auto-Focus
High Speed Mechanical Shutter and Strobe
DMX, RDM, Art-NET, and sACN Protocol Support
Elation’s E-FLY™ Internal Wireless DMX Transceiver



Specifications

SOURCE
Philips™ MSD Platinum 14R 280W 80CRI, 7,800K
1,500 Hour Average LAMP Life*
*May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.


PHOTOMETRIC DATA
136,800 LUX 12,709 FC @49.2 ft (15m) 2.5°


EFFECTS
5 and 32 Facet Rotating Prism and Prism Macros
Frost Filter Hybrid Wash Effect
Motorized Focus and Auto Focus
High Speed Mechanical Shutter and Strobe


COLOR
13 Dichroic Colors including CTB, CTO, and UV
Full CMY Color Mixing


GOBOS
(8) Interchangeable Rotating / Indexing Metal Gobos
(13) Static-Stamped Metal Gobos


CONTROL / CONNECTIONS
(3) DMX Channel Modes (28 total channels)
6 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
8 / 16 Bit Resolution Adjustable Movement
DMX, RDM, Art-NET, and sACN Protocol Support
Elation E-Fly™ Internal Wireless DMX Transceiver
IP65 5pin DMX In/Out
IP65 RJ45 Ethernet In/Out
IP65 powerCON TRUE1 Power In


SIZE / WEIGHT
Length: 17.1” (445mm)
Width: 17.87” (454mm)
Vertical Height: 26.77” (680mm)
Weight: 77.0 lbs. (35.0kg)


ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
500W Max Power Consumption
14°F to 113°F (-10°C to 45°C)


APPROVALS / RATINGS
CE | cETLus | IP65
Item#:
PRB014
Available:
Special Order/Direct Ship
You must be logged in to order this item. Log in here

Elation ZCL 360i

RGBW 60W LED-Single Beam Moving Head Fixture
FEATURES
Powerful 4° Single Beam Moving Effect Luminaire with Zoom
90W RGBW 4-in-1 LED
4° to 44° Motorized Zoom
New Advanced Collimator Optic Lens
Laser-Like Homogenized Color Changing Beam
Fast and Precise 16-Bit Continuous 360° Pan/Tilt Rotation
Flicker Free Operation for Broadcast TV and FILM

SOURCE
90W RGBW 4-in-1 LED
100,000 Hour Average LED Life*

*LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.


PHOTOMETRIC DATA
11,123 LUX 1,033 FC @9.8' (3m) (4° Min Zoom) Full ON
483 LUX 45 FC @9.8' (3m) (44° Max Zoom) Full ON

COLOR
RGBW

EFFECTS
RGBW Color Mixing
4° - 44° Beam Zoom Range
Variable Dimming Curves
Electronic Strobe and Dimming (0% - 100%)
64 Color Presets and 14 Unique Color Macros

CONTROL / CONNECTIONS
(3) DMX Channel Modes (21 Total Channels)
RDM (Remote Device Management)
(7) Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
8 / 16 Bit Resolution Adjustable Movement
5pin XLR In/Out
RJ45 etherCON In/Out (KlingNET / Art-NET)
powerCON Power In/Out

SIZE / WEIGHT
Length: 8.74" (222.1mm)
Width: 7.31" (186mm)
Vertical Height: 13.22" (336mm)
Weight: 13 lbs. (5.9 kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
101W Max Power Consumption
5F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS
CE | RoHs | IP30
Item#:
ZCL301
Available:
Special Order/Direct Ship
You must be logged in to order this item. Log in here
