1 - 7 of 7
View:

Description
Price
Quantity

Elation Cuepix Blinder WW4

100W Warm White LED Blinder/ 4 Cell

Features

  • High Power Long Life Warm White COB LEDs
  • 62° Beam Angle / 100° Field Angle
  • Individual Control of Each COB Module
  • 5 Variable Dimming Curve Modes
  • RDM (Remote Device Management)
  • Flicker FREE Operation for TV and FILM

Specifications

SOURCE
(4) 100W Warm White 3,200K COB LEDs
100,000 Hour Average Life*
 *LED Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

 PHOTOMETRIC DATA
12,300 LUX 1,143 FC @3.3’ (1M) / 3,200K
EFFECTS
Strobe
Dimming : 0% - 100% of Each COB Module
Variable Dimming Curves
CONTROL / CONNECTIONS
6 DMX Channel Modes (1 / 2 / 4 / 5 / 7 / 9)
4 Button Control Panel and LCD Menu Display
3pin and 5pin DMX In/Out
RDM* (Remote Device Management)  *Software Version 1.13 or Higher
powerCON Power In/Out
SIZE / WEIGHT
Length: 15.7" (400mm)
Width: 6.9" (174mm)
Horizontal Height: 17.4" (441mm)
Weight: 21.0 lbs. (9.5kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
427W Max Power Consumption
5°F to 113°F (-15°C to 45°C)
APPROVALS / RATINGS
CE | IP20
INSTALLATION
Rigging: Integrated Yoke and Side Mounting Brackets
Working Position: Any (360°)
INCLUDED ACCESSORIES
(1) Power Cable
Item#:
CUE242
Available:
Special Order/Direct Ship

Elation Cuepix Blinder WW4 Spec Sheet
Elation Cuepix Blinder WW4 User Manual
1160.00
Each

Elation Cuepix Blinder WW2

100W Warm White LED Blinder/ 2 Cell

Features

  •  High Power Long Life Warm White COB LEDs
  •  60° Beam Angle / 80° Field Angle
  •  Individual Control of Each COB Module
  •  Dimming: 0% - 100% of Each COB Module
  •  RDM (Remote Device Management)
  •  Flicker FREE Operation for TV and FILM
  •  Stand Alone Operation with Master/Slave Function
  •  Integrated Rigging Bracket

Specifications

SOURCE
(2) 100W Warm White 3,200K COB LEDs
100,000 Hour Average Life*
 *LED Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

 PHOTOMETRIC DATA
5900 Max LUX (548 fc) @1M (Full On)

 EFFECTS
Strobe
Variable / Selectable Dimming Curves

 CONTROL / CONNECTIONS
4 DMX Channel Modes (1 / 2 / 3 / 4)
4 Button Control Panel and LCD Menu Display
3pin and 5pin DMX In/Out
RDM* (Remote Device Management)  *Software Version 1.13 or Higher
powerCON Power In/Out
SIZE / WEIGHT
Length: 18.8” (478 mm)
Width: 7.1” (181.2 mm)
Horizontal Height: 10.2” (259.4 mm)
Weight: 11.2 lbs. (5.1 kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
229W Max Power Consumption
-14°F to 113°F (-10°C to 45°C)
APPROVALS / RATINGS
CE | cETLus | IP20
INCLUDED ACCESSORIES
(1) powerCON Cable
Item#:
CUE265
Available:
Special Order/Direct Ship

Elation Cuepix Blinder WW2
708.00
Each

Elation DTW350 IP

2 Beam LED Blinder/ IP65 Rated
FEATURES
IP65 Rated
Pixel Control
78° Wide Beam Angle
25° Narrow Beam Filters (included)
Independent Dim-to-Warm Channel Control (1,800K - 3,200K)
RDM (Remote Device Management)
Rugged Die-Cast Aluminum Exterior
Flicker Free Operation for TV and FILM

SOURCE
(2) 175W 2-in-1 Warm White/Amber COB LEDs
100,000 Hour Average Lamp Life*

*LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.


PHOTOMETRIC DATA (Full ON)
6,274 LUX 583 FC (78° Beam @ 3.3 ft / 1m)
41,040 LUX 3,813 FC (25° Beam @ 3.3 ft / 1m)

EFFECTS
Strobe
Independent Dimming of Each COB LED Module
Variable Dimming Curves
Independent Dim-to-Warm Channel Control (1,800K - 3,200K)

CONTROL / CONNECTIONS
Multiple DMX Channel Modes
4 Button Control Panel and LCD Menu Display
RDM (Remote Device Management)
IP Rated DMX and Power In/Out

SIZE / WEIGHT
Length: 15.7" (400mm)
Width: 9.5" (241mm)
Horizontal Height: 9.6" (245mm)
Weight: 18.0 lbs. (8.2 kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
Max Power Consumption: pending
5°F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS
CE | IP65

INCLUDED ACCESSORIES
(1) Power Cable
Item#:
DTW350
Available:
Special Order/Direct Ship
1099.99
Each

Elation DTW700 IP

4 Beam LED Blinder/ IP65 Rated
FEATURES
IP65 Rated
Pixel Control
78° Wide Beam Angle
25° Narrow Beam Filters (included)
Independent Dim-to-Warm Channel Control (1,800K - 3,200K)
RDM (Remote Device Management)
Rugged Die-Cast Aluminum Exterior
Flicker Free Operation for TV and FILM

SOURCE
(4) 175W 2-in-1 Warm White/Amber COB LEDs
100,000 Hour Average Lamp Life*

*LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.


PHOTOMETRIC DATA
10,360 LUX 962 FC (78° Beam @ 3.3 ft / 1m)
49,020 LUX 4,554 FC (25° Beam @ 3.3 ft / 1m)

EFFECTS
Strobe
Independent Dimming of Each COB LED Module
Variable Dimming Curves
Independent Dim-to-Warm Channel Control (1,800K - 3,200K)

CONTROL / CONNECTIONS
Multiple DMX Channel Modes
4 Button Control Panel and LCD Menu Display
RDM (Remote Device Management)
IP Rated DMX and Power In/Out

SIZE / WEIGHT
Length: 15.7" (400mm)
Width: 9.5" (241mm)
Horizontal Height: 16.1" (410mm)
Weight: 28.0 lbs. (12.7 kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
Max Power Consumption: pending
5°F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS
CE | IP65

INCLUDED ACCESSORIES
(1) Power Cable
Item#:
DTW700
Available:
Special Order/Direct Ship
1899.99
Each

Elation Paladin

RGBW LED Strobe/Wash/Blinder Fixture w/Motorized Zoom-IP65 Rated

Features

    • IP65 Rated Strobe Wash Blinder Luminaire
    • (24) 40W 4-in-1 RGBW LEDs
    • Motorized Zoom and Manual Tilt Adjustment
    • Pixel Zone Control
    • 64 Color Presets and 15 Unique Program Macros
    • 16-Bit Dimming and Variable Dimming Curves
    • Flicker Free for TV and FILM
    • Adjustable Refresh Rate Frequency and GAMMA
    • Rugged Die-Cast Aluminum Exterior
    • Optional Barn Doors and Egg Crate Available
    • Dual Quick-Lock Omega Bracket Rigging Option

    Specifications

    SOURCE
    (24) 40W 4-in-1 RGBW LEDs
    50,000 Hour Average LED Life
    *May vary depending on several factors including but not limited to:
    Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.


    PHOTOMETRIC DATA
    79,252 LUX 7,362 FC @9.8’ (2m) (6° Full ON)
    6,848 LUX 636 FC @9.8’ (2m) (32° Full ON)

    COLOR
    RGBW

    EFFECTS
    Pixel Zone Control
    64 Color Presets and 15 Unique Color Macros
    Electronic Strobe
    16-Bit Dimming and Variable Dimming Curve Modes

    CONTROL / CONNECTIONS
    6° to 32° Motorized Zoom
    Manual 210° Tilt Movement
    Multiple DMX Channel Modes (33 total channels)
    Adjustable Refresh Rate and Gamma Brightness
    4 Button Control Panel and LCD Menu Display
    RDM (Remote Device Management)
    IP Rated 5pin DMX In/Out
    powerCON TRUE1 In


    SIZE / WEIGHT
    Length: 16.4” (478mm)
     Width: 11.2” (233mm)
     Vertical Height: 16.0” (407.5mm)
     Weight: 46.0 lbs. (20.9 kg)


    ELECTRICAL / THERMAL
    AC 100-240V - 50/60Hz
    990W Max Power Consumption
    5°F to 113°F (-15°C to 45°C)


    APPROVALS / RATINGS
    CE | IP65

Item#:
PAL001
Available:
Special Order/Direct Ship

Elation Paladin Spec Sheet
Elation Paladin User Manual
2800.00
Each

Elation Protron 3K White

LED White Strobe
FEATURES
120° Beam Angle
(2) Power Modes (HIGH and LOW)
(2) Silent Cooling Fans

SOURCE
(202) CREE 3W Cool White LEDs
80,000 Total Lumens
50,000 Hour Average LED Life**

**LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.


PHOTOMETRIC DATA
16,450 LUX 1,528 FC @3.3' (1m) (120° Full ON)

EFFECTS
Electronic Dimming
Burst, Pulse, Lighting, Full ON*
*Thermally regulated output at full max 10 seconds.

CONTROL / CONNECTIONS
3 DMX Channel Modes (1 / 2 / 3 / 4)
4 Button Control Panel
LCD Menu Display
3/5pin DMX In/Out
powerCON In/Out
Power Link Up To (2) Units at 120V

SIZE / WEIGHT
Length: 21.5" (546mm)
Width: 6.9" (175mm)
Vertical Height: 11.7" (296mm)
Weight: 17.2 lbs. (7.8kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
900W Max Power Consumption
Max Ambient Temperature 113°F (40°C)

APPROVALS / RATINGS
CE | cETLus | IP20

INSTALLATION
Rigging: Integrated Yoke
Working Position: Any (360°)

INCLUDED ITEMS
(1) powerCON Cable
Item#:
PRO890
Available:
Special Order/Direct Ship

Elation Pro890 User Manual
Elation Pro890 Spec Sheet
899.99
Each

Elation Protron 3K RGBW

RGBW LED Strobe Light
FEATURES
63° Beam Angle
(2) Power Modes (HIGH and LOW)
Electronic Dimming
(2) Silent Cooling Fans
Burst, Pulse, Lightning, and Full ON* Effects

*Thermally regulated output at full max 10 seconds.


SOURCE
(240) CREE XLamp 3W LEDs (60 each color-RGBW)
50,000 Hour Average LED Life**

**LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.


PHOTOMETRIC DATA
40,000 Total Lumens* (*Peak)
12,210 LUX 1,134 FC @3.3' (1m) (63° Full ON)

COLOR
RGBW

EFFECTS
Electronic Dimming
Burst, Pulse, Lightning, Full ON*

*Thermally regulated output at full max 10 seconds.


CONTROL / CONNECTIONS
(4) DMX Channel Modes (3 / 5 / 7 / 8)
4 Button Control Panel
OLED Menu Display
3/5pin DMX In/Out
powerCON TRUE 1 In/Out

SIZE / WEIGHT
Length: 19.9" (506mm)
Width: 5.9" (150mm)
Vertical Height: 14.1" (357mm)
Weight: 24.3 lbs. (11.0kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
800W Max Power Consumption
Max Ambient Temperature 113°F (40°C)

APPROVALS / RATINGS
CE | IP20

INSTALLATION
Rigging: Integrated Yoke
Working Position: Any (360°)

INCLUDED ITEMS
(1) powerCON TRUE1 Cable
Item#:
PRO901
Available:
Special Order/Direct Ship

Elation Protron 3K RGBW Spec Sheet
Elation Protron 3K RGBW User Manual
1399.99
Each
1 - 7 of 7
