1 - 2 of 2
View:

Description
Price
Quantity
 APPLICATIONS
Ballrooms
Restaurants
Houses of worship
Multi-purpose rooms
Small corporate meeting rooms
Small performance spaces
FEATURES
 6 20A dimmers, 120V, wall mount
Capable of dimming multiple load types: incandescent, low voltage, two-wire fluorescents
Versatile control via DMX-512 and/or SmartLink
DMX addressing and softpatch via keypad
Built-in presets (32) and sequencer with programmable fade and hold times allow stand-alone operation
SmartLink provides synchronization of presets and sequences across multiple packs
Optional LinkPower Supply powers four stations
Auto-Restart returns to previous state after power cycled
Control-power switch puts unit in standby mode
Multi-language: English, Spanish, German and French
Fully rated magnetic circuit breakers
Bypass contact input instantly switches on selected loads, while switching others off
Full compliance with UL, cUL, FCC and CE regulations
 GENERAL
Approvals and certifications:
- Underwriters Laboratories tested and Listed to the following standards:
· UL508 (File: E152039)
- Complies with ESTA DMX512A Standards
ELECTRICAL
Maximum feed capacity:
- 3 x 40A, Three Phase, four-wire & ground
- 2 x 60A, Single Phase, three-wire & ground
Easily switches from single phase to three phase
Input voltage range from 85 – 140 VAC, 47 – 63 Hz
Input lugs rated for up to 2 AWG
Standard output connection via DIN Rail spring terminals, rated for up to 8 AWG
Fully rated magnetic circuit breakers to eliminate nuisance tripping
High-quality 200μs toroidal filters
Modular SCR and bonded heat sink assembly with superior surge, thermal transfer, and short-circuit immunity
2500V isolation between control and power components
CONTROL WIRING
Removable terminals for DMX512, SmartLink and Contact Input rated for maximum of 12AWG wire
MECHANICAL
16-gauge steel construction
Fine-textured, scratch-resistant paint
Removable knockout panels with pass-through plenum for side-by-side or top-to-bottom mounting configurations (sides, top and bottom)
Full front access (side clearance not required)
Optional rack-mount kit (requires 15U spacing)
Recessed control connectors and protected circuit breakers
THERMAL
Ambient temperature between 32°F (0°C) and 95°F (35°C)
Humidity between 30 – 95% (non-condensing)
Fan-forced airflow from bottom to top
Low-noise, temperature-controlled fan
Efficiency = 96% or better, maximum dissipation 3% of connected load (Max. 3,100 BTUs)
USER INTERFACE
High-contrast 20-character by two-line backlit LCD
Six-button blue phosphorescent keypad
Power status indicator LED (Blue)
SHIPPING INFO
 Ship Weight 53.0 lbs.

Item#:
7021A1100
Available:
Special Order/Direct Ship
1888.61
Each

ETC ES750-0A

Electronic Silent Dimmer; 750 watt w/ Edison
 FEATURES
  • ES Dimming technology
- Produces no lamp noise (exceeds all rise time specs)
- Electronics sound-pressure level less than 0 dBA at 1 meter
*Sound level pressure falls below minimum audible field 0-20 khz @ < 1 meter from unit
- Convection-cooled
  • ANSI E1.20 RDM and ANSI E1.11 DMX512A
  • Yoke-mount; Universal-mounting bracket included, direct mounting on a fixture yoke in multiple orientations to accommodate maximum flexibility
  • Local operation
- One-press dim to FULL for easy focusing (press again to release to DMX input)
- Up and down level control
- Returns to previous level after power loss
  • No electrical assembly required: Ships as complete kit with burner assembly - just mount to the yoke and place lamp burner at the back of an existing fixture Bare-end or connectorized power cable input (Edison, Stage, or Twistlock)
SPECIFICATIONS
GENERAL
  • Designed for use with all tungsten fixtures up to 750 watts
  • Electronic Silent technology for operation free of dimmer- and lamp-filament noise
  • Changes your fixture into a truly distributed fixture with onboard dimming and control
  • Electronic Dimming with harmonic and noise suppression - Acoustic specification replaces dimmer rise time
MECHANICAL
  • Manufactured of epoxy-painted aluminum body and anodised aluminum heat sink
  • Multiple yoke-fixing hole combinations for flexible mounting to the fixture
  • Convection-cooled; operates without cooling fans
  • Available in three colors: Black, White, or Silver
ELECTRICAL
  • Input power feed:
- Suggested breaker sizing: 20A
- Voltage ranges: 85-140V, 180-260V
- Frequency range: 47-63Hz
  • 115V output regulation options for 208V operation:
  • Bare-end or connectorized power cable input (Edison, Stage Pin, or Twist)
  • 2500V isolation between control and power components
  • Max output 750W
  • DMX* In and Thru
  • DMX thru is not self-terminating
  • Electronic overcurrent protection
*Represents 1/4 unit device load for purpose of calculating DMX daisy -chain device count (max 32 unit devices per DMX chain)
THERMAL
  • Maximum ambient temperature 104°F
  • Humidity between 10 - 95%, non-condensing
  • Convection-cooled
  • Optimum cooling when mounted with heatsink fins in vertical position
  • 171 Btu at full load
CONTROL FEATURES
  • DMX512A/RDM In and Thru via 5-Pin XLR connectors
  • Supports up to 32 units on one DMX line
  • RDM features:
- Discover (flashes light output)
- Find and set DMX address
- Change curve
- Receive overcurrent/undercurrent warnings
- Receive over temperature warning
  • Three-button local control: focus/test, up and down
- Single button dim to full for focus
- Up/down buttons for setting DMX address or for local intensity control
  • One status indicator: Multicolor LED for power, error and valid DMX
  • Three selectable dimmer output curves:
- IES modified square law
- Linear
- Switched (50% threshold)
Item#:
7145A1101-0A
Available:
Special Order/Direct Ship
456.73
Each
1 - 2 of 2
