Aryton 015160
MagicDot SX RGBW LED Moving Head Beam
MAGICDOT-SX delivers up to 75% optical efficiency in a tight beam, when the 94 mm diameter collimator is positioned close to the transmitting lens.
This ensures great compatibility and graphical interactivity with MAGICDOT-R units. In addition to DMX-RDM control, MAGICDOT-SX can be controlled via wireless CRMX TiMo RDM from LumenRadio™. MAGICDOT-SX is a versatile tool that meets a vast array of needs both in stage and architectural applications.
Technical specifications
Optics
2-elements 8:1 zoom high-resolution optic system
Beam aperture: 5° to 40°
Fast motorised linear zoom
75% optic efficiency
94mm PMMA collimator optic
Light source
2,000 lumens RGBW High-Power LED source
Total luminaire output: up to 1,500 lumens
Luminous intensity: 136,000 cd (narrow beam)
Rated life (L70): up to 40,000 hours
Flicker free sources management, suitable for TV applications and all video recorded events
Movement
Extremely accurate positioning
Moving-head operated via either 8- or 16-bit resolution
High-resolution stepper motors operated via microprocessors ensure extreme accuracy and smooth movements.
Pan and tilt automatic repositioning
Moving-head range: infinite pan and tilt rotation
Colours
Sophisticated 4 colours RGBW mixed, reaching high Colour Rendering Index
Light beam with no colour shadows, and rich saturated and pastel colour-hues
4.29 billion colours (8 bit resolution)
Virtual colour wheel, including most usuals white colour temperature presets
Dynamic colour macro effect with variable speed
Dimmer / strobe
Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation
White or colour strobe effect, with speed adjustment from 1 to 25 flashes per second
Software features
Local DMX addressing of luminaire and optional parameters through its built-in LCD control panel
Remote DMX addressing of luminaire and optional parameters through a standard RDM DMX controller
Information menu including hour counter, temperature, software version
Hardware features
Graphic LCD display for addressing and special functions settings, with flip function
6 menu buttons to set the functions
Excess temperature protection
Integrated wireless CRMX RDM receiver from LumenRadio™
XLR 5 pin male and female connectors for DMX connection
powerCON TRUE1 male and female connectors for power connection
Control
DMX 512 protocol, through DMX cable or wireless system
DMX-RDM compatible
Stand-alone mode and Master/Slave modes
Local control panel, with LCD display
Choice of 2 DMX modes (from 16 to 19 DMX channels)
Power supply
Electronic supply with active PFC
100 to 240 Volts – 50/60 Hz
Power 130 W maximum
Cooling system
Advanced cooling system
Self adjusting variable speed fans for quiet operation (Auto mode)
Selectable auto, stage & studio ventilation modes
Safety protection against temperatures excesses
Housing
Moving-head skeleton made of aluminium and steel metal plates
Heatsinks in aluminium
Moulded covers in self-extinguishing fire retardant ABS PC (V0 class)
Two sides handles for transportation
Four heavy-duty feet for better stability
IP20 protection rating
Exterior finish: black (Carbon)
Installation
Fastening brackets system: one Omega 1/4 turn brackets designed for use with standard clamps
Mounting points: two 1/4 turn locking fittings allowing installation of Omega brackets on luminaire
Safety cable attachment point
Operating parameters
Operating positions: all (device on floor or fixed to a support)
Maximum permitted ambient temperature (Ta max): 45 °C (113 °F)
Minimum permitted ambient temperature (Ta min): -10 °C (14 °F)
Minimum usage distance: 1.0 m (3.28 ft)
Compliance
EU (EMC):
EMC Directive 2014/30/EU
EU (LVD):
LVD Directive 2014/35/EU
Size
Product: 210 x 318 x 210 mm (l x h x d)
Flight-case foam: 251 x 330 x 251 mm (l x h x d)
Weight
Product: 5.7 kg
Product codes
015160: MAGICDOT-SX CREATIVE SOLUTION
Item#:
AY015160
Available:
Special Order/Direct Ship
1920.00
Each
Aryton 015170
MagicDot XT RGBW LED Moving Head Beam
The minimalist cylindrical design of the MagicDot-XT is a scaled-up version of MagicDot-R.
The new luminaire sports all same features, including ultra-rapid movement and continuous, unlimited, rotation on pan and tilt. The compact footprint permits multiple MAGICDOT-XT luminaires to be installed with a minimum amount of space between them. In addition to standard DMX-RDM connectors, MAGICDOT-XT can be controlled via wireless CRMX TiMo™ RDM from LumenRadio™.
Technical specifications
Technical specifications
Optics
Beam aperture: 2°
85% optic efficiency
126mm PMMA collimator optic
Light source
1,000 lumens RGBW High-Power LED source
Total luminaire output: up to 850 lumens
Luminous intensity: 580,000 cd (narrow beam)
Rated life (L70): up to 40,000 hours
Flicker free sources management, suitable for TV applications and all video recorded events
Movement
Extremely accurate positioning
Moving-head operated via either 8- or 16-bit resolution
High-resolution stepper motors operated via microprocessors ensure extreme accuracy and smooth movements.
Pan and tilt automatic repositioning
Moving-head range: infinite pan and tilt rotation
Colours
Sophisticated 4 colours RGBW mixed, reaching high Colour Rendering Index
Light beam with no colour shadows, and rich saturated and pastel colour-hues
4.29 billion colours (8 bit resolution)
Virtual colour wheel, including most usuals white colour temperature presets
Dynamic colour macro effect with variable speed
Dimmer / strobe
Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation
White or colour strobe effect, with speed adjustment from 1 to 25 flashes per second
Software features
Local DMX addressing of luminaire and optional parameters through its built-in LCD control panel
Remote DMX addressing of luminaire and optional parameters through a standard RDM DMX controller
Information menu including hour counter, temperature, software version
Hardware features
Graphic LCD display for addressing and special functions settings, with flip function
6 menu buttons to set the functions
Excess temperature protection
Integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™
XLR 5 pin male and female connectors for DMX connection
powerCON TRUE1 male and female connectors for power connection
Control
DMX 512 protocol, through DMX cable or wireless system
DMX-RDM compatible
Stand-alone mode and Master/Slave modes
Local control panel, with LCD display
Choice of 2 DMX modes (from 15 to 17 DMX)
Power supply
Electronic supply with active PFC
100 to 240 Volts – 50/60 Hz
Power 100 W maximum
Cooling system
Advanced cooling system based on heatpipe technology
Self adjusting variable speed fans for quiet operation (Auto mode)
Selectable auto, stage & studio ventilation modes
Safety protection against temperatures excesses
Housing
Moving-head skeleton made of aluminium and steel metal plates
Heatsinks in aluminium and copper, satin finish
Moulded covers in self-extinguishing fire retardant ABS PC (V0 class)
Two sides handles for transportation
Four heavy-duty feet for better stability
IP20 protection rating
Exterior finish: black (Carbon)
Installation
Fastening brackets system: one Omega 1/4 turn brackets designed for use with standard clamps
Mounting points: two 1/4 turn locking fittings allowing installation of Omega brackets on luminaire
Safety cable attachment point
Operating parameters
Operating positions: all (device on floor or fixed to a support)
Maximum permitted ambient temperature (Ta max): 45 °C (113 °F)
Minimum permitted ambient temperature (Ta min): -10 °C (14 °F)
Minimum usage distance: 2.0 m (6.56 ft)
Compliance
EU (EMC):
EMC Directive 2014/30/EU
EU (LVD):
LVD Directive 2014/35/EU
Size
Product: 235 x 360 x 235 mm (l x h x d)
Flight-case foam: 290 x 355 x 290 mm (l x h x d)
Weight
Product: 6.2 kg
Product codes
015170: MAGIDOT-XT CREATIVE SOLUTION
Item#:
AY015170
Available:
Special Order/Direct Ship
1815.00
Each
Aryton 015350
MagicBlade FX RGBW LED Moving Head Linear Wash
The MAGICBLADE-FX has seven next-generation RGBW high-output LEDs that can be individually controlled to create airborne virtual scenery or to illuminate sets and performers.
The crisp, clean separation between LED sources permits designers to develop innovative graphic effects. An onboard library of pre-programmed effects and colour macros can be combined with console driven control in various display modes. MAGICBLADE-FX has extended serial connectivity and can be controlled DMX-512 w/ RDM, ArtNet™, sACN or a wireless link with CRMX TiMo RDM from LumenRadio™.
Technical specifications
Optics
2-elements 15:1 zoom high-resolution optic system
Beam aperture: 3.6° to 53°
Fast motorised linear zoom
7 squared 65 mm frontal lens
Light source
7 x 1,000 lumens RGBW High-Power LED source
Total luminaire output: up to 4,200 lumens
Luminous intensity: 579,600 cd (narrow beam)
Rated life (L70): up to 40,000 hours
Flicker free sources management, suitable for TV applications and all video recorded events
Movement
Extremely accurate positioning
Moving-head operated via either 8- or 16-bit resolution
High-resolution stepper motors operated via microprocessors ensure extreme accuracy and smooth movements.
Pan and tilt automatic repositioning
Moving-head range: infinite pan and tilt rotation
Colours
Sophisticated 4 colours RGBW mixed, reaching high Colour Rendering Index
Uniform light beam with no colour shadows, and rich saturated and pastel colour-hues
4.29 billion colours (8 bit resolution)
Virtual colour wheel, including most usuals white colour temperature presets
Dynamic colour macro effect with variable speed
Effects
2D & 3D graphical effects capabilities
Effects can be coupled with beam, wash or matrix applications
Built-in pattern effects with speed and fade controls for scenic applications
Dimmer / strobe
Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation
White or colour strobe effect, with speed adjustment from 1 to 25 flashes per second
Software features
Local DMX addressing of luminaire and optional parameters through its built-in LCD control panel
Remote DMX addressing of luminaire and optional parameters through a standard RDM DMX controller
Information menu including hour counter, temperature, software version
Hardware features
Graphic LCD display for addressing and special functions settings, with flip function
6 menu buttons to set the functions
Excess temperature protection
Integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™
XLR 5 pin male and female connectors for DMX connection
etherCON RJ45 IN / OUT connectors for ArtNet™ & sACN connection
powerCON TRUE1 male and female connectors for power connection
Control
DMX 512 protocol, through DMX cable or wireless system
DMX-RDM compatible
Stand-alone mode and Master/Slave modes
ArtNet™ & sACN protocol through Ethernet cable
Local control panel, with LCD display
Choice of 3 DMX modes (from 19 to 46 DMX channels)
Power supply
Electronic supply with active PFC
100 to 240 Volts – 50/60 Hz
Power 400 W maximum
Cooling system
Advanced cooling system
Self adjusting variable speed fans for quiet operation (Auto mode)
Selectable auto, stage & studio ventilation modes
Safety protection against temperatures excesses
Housing
Moving-head skeleton made of aluminium and steel metal plates
Heatsinks in aluminium
Moulded covers in self-extinguishing fire retardant ABS PC (V0 class)
Two sides handles for transportation
Four heavy-duty feet for better stability
IP20 protection rating
Exterior finish: black (Carbon)
Installation
Fastening brackets system: two Omega ¼ turn brackets designed for use with standard clamps
Mounting points: four ¼ turn locking fittings allowing installation of Omega brackets on luminaire
Safety cable attachment point
Operating parameters
Operating positions: all (device on floor or fixed to a support)
Maximum permitted ambient temperature (Ta max): 45 °C (113 °F)
Minimum permitted ambient temperature (Ta min): -10 °C (14 °F)
Minimum usage distance: 1.5 m (4.92 ft)
Compliance
EU (EMC):
EMC Directive 2014/30/EU
EU (LVD):
LVD Directive 2014/35/EU
Size
Product: 612 x 312 x 191 mm (l x h x d)
Flight-case foam: 677 x 370 x 250 mm (l x h x d)
Weight
Product: 13.0 kg
Product codes
015350 : MAGICBLADE-FX CREATIVE SOLUTION
Item#:
AY015350
Available:
Special Order/Direct Ship
3832.50
Each
