Description
Price
Quantity
TRUSST CTC-50HC
Half-Coupler w/ M12 Bolt, Silver
Features
- Half-coupler clamp made of heavy duty extruded aluminum
- Built with versatility, safety and durability in mind
- 360-degree wrap around style won’t scratch or damage truss
- Fits the CT290 series and other major brands of truss
- Heavy duty captive T-handles for easy installation
- Ideal for hanging light fixtures from truss and pipe systems
Specifications
- Color: Natural aluminum, clear anodized
- Threaded Bolt: M12
- Load capacity: 1,650 lb (750 kg)
- Fits: 2 inch (50 mm) truss
- Weight: 1.4 lb (0.6 kg)
- Dimensions: 5.75 x 1.9 x 4.5 in (146 x 50 x 114 mm)
Item#:
CTC-50HC
Available:
Special Order/Direct Ship
42.11
Each
Mega-Coupler ML9B
90º Coupler w/ Wing Nut, Black Anodized
Item#:
ML9B
Available:
Special Order/Direct Ship
51.45
Each
Mega-Coupler ML9B-NN
90 Degree Fixed coupled w/ Nylock Nuts, Black
Minimum Size
1.25" pipe, 1.66" OD pipe
Maximum Size
2" OD truss tube,1.5" pipe, 1.90" OD pipe
Working Load Limit
1100 Pounds
Weight
2.2 Pounds
1.25" pipe, 1.66" OD pipe
Maximum Size
2" OD truss tube,1.5" pipe, 1.90" OD pipe
Working Load Limit
1100 Pounds
Weight
2.2 Pounds
Item#:
ML9B-NN
Available:
Special Order/Direct Ship
51.45
Each
The Light Source ML9M-XL-RKIT
90 Degree Fixed Mega-Coupler XL Joining Plate Kit
Includes bolt, nut, and plate. Use with two Mega-Couplers to create a fixed 90 degree coupler. This stronger version eliminates twisting or rocking due to vibrations.
Item#:
ML9M-XL-RKIT
Available:
Special Order/Direct Ship
8.15
Each
Mega-Coupler MLB
1/2" Hex Head Bolt, Black Anodized
| Minimum Size | 1.25" pipe, 1.66" OD pipe |
| Maximum Size | 1.5" pipe, 1.90" OD pipe, 2" OD truss tube |
| Safe Vertical Working Load | 1,100 lb / 500kg |
| Hardware | Standard Hardware ½-13 x 1 ¼" Hex Head grade 8 zinc plated steel bolt with nylock nut 1" Belleville Washer |
| Weight | 1.2 pounds |
Item#:
MLB
Available:
Special Order/Direct Ship
25.26
Each
Mega Coupler MLB-M12CS
M12 Flat Head Bolt and Metric Hardware, Black Anodized
Item#:
MLB-M12CS
Available:
Special Order/Direct Ship
26.67
Each
Mega-Coupler MLBSE
Mega Coupler with Eye Bolt, Black Anodized
Item#:
MLBSE
Available:
Special Order/Direct Ship
39.18
Each
Mega-Coupler MLM
1/2" Hex Head Bolt, Aluminum Finish
Item#:
MLM
Available:
Special Order/Direct Ship
21.24
Each
The Light Source MLM1/2CS
Mega-Coupler with 1/2" Countersunk Flat Head Bolt, Silver
Minimum Size
1 1/4" pipe, 1.66OD truss tube
Maximum Size
2" pipe, 2.050OD truss tube
Working Load Limit
1100 pounds
Hardware
1/2″ × 1.5″ flat head bolt or
3/8″ × 1.5″ flat head bolt
Nylock Nut
Belleville Washer
Weight
1.1 pounds
1 1/4" pipe, 1.66OD truss tube
Maximum Size
2" pipe, 2.050OD truss tube
Working Load Limit
1100 pounds
Hardware
1/2″ × 1.5″ flat head bolt or
3/8″ × 1.5″ flat head bolt
Nylock Nut
Belleville Washer
Weight
1.1 pounds
Item#:
MLM1/2CS
Available:
Special Order/Direct Ship
21.24
Each
Mega-Coupler MLMSE
Mega-Coupler with Eye Bolt, Aluminum Finish
Item#:
MLMSE
Available:
Special Order/Direct Ship
36.11
Each
Mega-Coupler MLSB
Double Swivel Coupler w/ Wing Nut, Black Anodized
Item#:
MLSB
Available:
Special Order/Direct Ship
51.45
Each
