Home  >  Power Distribution Systems and Panels  >  Power Distribution Systems  > Entertainment Power Systems DVA300

Entertainment Power Systems DVA300

200A Rack Mount 3-Phase Meter Kit w/ Current Transformers
Item #:2-000-000-0023
Available: Special Order/Direct Ship
Entertainment Power Systems EPS DVA300 Smart View™ Power Meter is a UL Listed 2-space, rack mount 3-phase digital power meter designed for use in portable or installed applications. This device performs voltage, frequency and current measurement functions.


- Split core current transformers are included for 200A metering capabilities.
- Includes Voltage Wire Kit for easy installation.


The DVA300 is UL Listed for installation in the field, in third party devices.
Contact us to order
Features
  • EPS Smart View™ - Allows users to monitor voltage on all three phases simultaneously.
  • Large, Daylight Readable Meters
  • Numeric and graph bar readout
  • Current / Voltage / Frequency metering for all phases
  • Ground voltage metering
  • Neutral current metering
  • Out of range visual warning
  • Compact 2 rack space design
  • Designed for use in a wide variety of rack mount applications
  • Durable black powder coat finish
  • UL Listed for installation in the field

Current Transformers  - Includes (4) 200A Split Core Current Transformers

  • Current transformers UL Listed - Category XOBA to maintain UL listing on the DVA300 meter when installed
  • Current transformers are rated for the primary current to be measured, and have a rated output of 1A
  • Split core current transformers provided, allowing for easy installation around conductors

Dimensions and weight (Not including current transformers)

  • 19” Wide (482.6 mm)
  • 7-1/8” Deep (8-1/4” deep including handles)  (181 mm)  (209.6 mm)
  • 3-1/2” High (88.9 mm)
  • 7.95 lbs.  (3.6 kg)
Certification

  • cULus Listed - E499094
Environmental
  • IP20 (indoor) rated
  • Operational Temperature Range:  -20° F to 140° F (-29° C to 60° C)
  • Humidity:  0% to 80% non-condensing humidity
  • Altitude to 2000 meters (6500’)
What's Included
  • (1) DVA300 Meter
  • (4) 200A Split Core Current Transformers
  • (1) Voltage Wire Kit
